     MoDaR (Molecular Dynamics package at Ryan Research)




      BeeMD Dev. Team 收人,如感兴趣请入群,   微信群:BeeMD开发  QQ群: 222316924

    • 现有开发团队简介

    • 对MD开发感兴趣,学历不限,最好有比较扎实的数学、物理和C/C++语言基础。
    • 现有的团队成员负责为新成员进行基础开发培训
    • 开发成果可自由用于学术研究和课题工作



      About Modar

    • Modar is a software package for molecular dynamics (MD) simulation, including modeling, sampling, and result analysis. Whole package is coded in C++/C language, and powered with OPENMP, CUDA, MPI Parallelization.
    • A simple and easy script language is implemented in Modar for carrying out all relevant functions needed for MD simulation. Taking the advantage of the flexibility of script language, Modar can help user realize advanced level modeling, reslult analyzing, even do some algorithm and methodology study jobs without playing with the source code.
    • Modar is free for all academic or nonprofit researching purposes. Currently the source code is not ready to be open yet, but we do welcome any academic group or researchers to join the development team to help us to make it more powerful and more extendable.


     Downloads (Jun06-2014)

    • Prebuild binaries for Linux x86_64, 64bit

    • Prebuild binaries for Linux i686, 32bit

    • Prebuild binaries for MS Windows, XP up (natively not CYGWIN needed)

    • Prebuild binaries for MacOSX, x86, Tiger up

    • The visualization tool Movar is already packed in the balls
    • Modar is totally portable for all platforms; please see “readme.txt” in the package for more details.


      Run a MD job using Modar

    • ./modar run.inp

      Where “run.inp” is an input scipt file composed in Modar script language, and the log messages will be printed to a log file, which has the same file name of the input file but with a “.log”, and it will be “run.log” in this example. The timing information (how long the job will take) and the size of  trajectory file will be reported on the fly on screen.
    • Please see modar command manpage here for more information





     Documents and examples

    • BeeMD Wiki for both Users and Developers

    • A quick guide to Modar script language

    • A brief introduction to MD simulation

    • Example 1: Building a water box

    • Example 2: PMF of displacement of ions pairs in water

    • Example 3: Ion liquid simulation

    • Example 4: Protein simulation in explicit solvent

    • Example 5: Base flipping in RNA by Steered MD

    • Example 6: Quick PMF evaluation for protein and ligand binding

    • Example 7: Membrane simulation: building a lipid bilayer

    • Example 8: Membrane simulation: drug molecule translocation

    • Modar commands list

    • Select expression

    • Availabe ensemble and integrator combinations in Modar

    • Modar MD energy profile viewer

    • Energy and relevant terms reported by Modar

    • Units measurement in Modar

    • File types in Modar




      Contact us

      Phone: 400-660-8656
      Email: support@beemd.org



    我们不定期和北京市计算中心合作开办使用培训研讨会(仅像征性收取会务费),愿意参加交流讨论的学友请和我们联系,凑够人数,确定时间后,北计发邀请函,地点在北计,每期20-30人,两天时间,北计赞助一些机时。

    请通过QQ报名:657997250, 验证请写:Modar使用交流

    有愿意参加开发的团队和个人请加QQ群: 222316924   MODAR MD Package 开发

  Cooperators and Sponsorers

    • 北京市计算中心
    • 中科院过程工程所
    • 中科院大连化物所
    • 中国科技大学
    • 中科院化学所
    • 北京生命科学研究所
    • 上海交通大学
    • 四川大学
    • 首都师范大学
